Product Positioning: A high-performance, high-safety electric pallet stacker designed to improve material handling efficiency in confined spaces, meeting the intensive operation needs of small and medium-sized warehouses.

Key Highlights:

Multiple Safety Guarantees: Utilizes national standard plate chains (replacing traditional roller chains), an emergency power-off button, a hydraulic system without oil pipes, and CAN-BUS intelligent fault diagnosis to ensure safe and reliable operation.

Powerful and Flexible Operation: Compact body and small turning radius, suitable for maneuvering nimbly in narrow aisles; maximum lifting height of 3910mm, covering various stacking needs.

Rugged and Durable Design: Thickened mast, solid metal outriggers, and a high-strength chassis, combined with superior welding technology, ensure long service life and high load capacity.

Applicable Scenarios:

Stacking and handling of goods in small and medium-sized warehouses and logistics centers

Back-of-house inventory management in supermarkets and retail stores

Material transfer and stacking operations in production lines and workshops

Designation	Lowered mast height h1(mm)	Free Lift height h2(mm)	Lift height h3(mm)	Extended mast height h4(mm)	Lift+fork height h3+h13(mm)
QES15E
Single stage mast	2080	−	1510	2080	1600
Two stage mast	1530	−	1910	2490	2000
	1780	−	2410	2990	2500
	2030	−	2910	3490	3000
	2180	−	3210	3790	3300
	2280	−	3410	3990	3500
	2530	−	3910	4490	4000
Two stage mast FFL (Full-Free-Lift)	−	−	−	−	−
Three stage mast	−	−	−	−	−
Three stage mast FFL (Full-Free-Lift)	−	−	−	−	−

		Manufacturer's type designation		QES15E
Distinguishingmark	1.3 Power(battery,diesel,petrol,gas,manual)			Battery

	1.4	Operator type	/	Pedestrian

	1.5	Load capacity/Rated load	Q(t)	1.5

	1.6	Load centre distance	C(mm)	600

	1.8	Load distance,centre of drive axle to fork	X(mm)	715

	1.9	Wheelbase	Y(mm)	1190

Weight	2.1	Service weight	kg	500

	2.2	Axle loading,laden front/rear	kg	620/1380

	2.3	Axle loading,unladen front/rear	kg	370/130

Tires,chassis	3.1	Tires	/	PU
	3.2	Tire size,front	◎×w(mm)	φ210×70
	3.3	Tire size,rear	◎×w(mm)	φ80×70
	3.4	Additional wheels(dimensions)	⑧×w(mm)	φ150×50

	3.4	Wheels,number front/rear(x=driven wheels)	/	1x+1/4
	3.6	Track,front	B10(mm)	540
	3.7	Track,rear	B11(mm)	400/520
Dimensions	4.2	Lowered mast height	Hi(mm)	1530
	4.3	Free Lift height	H2 (mm)	/
	4.4	Lift height	H3(mm)	1910
	4.5	Extended mast height	H4(mm)	2490
	4.9	Height oftiller in drive position min./max.	H14(mm)	690/1300
	4.15	Height,lowered	Hi3 (mm)	90
	4.19	Overall length	Li(mm)	1780
	4.20	Length to face of forks	l2(mm)	630
	4.21	Overall width	B1(mm)	800
	4.22	Fork dimensions	S/E/l(mm)	55/160/1070(1150)
	4.25	Distance between fork-arms	BS (mm)	560/685
	4.32	Ground clearance,centre of wheelbase	mz(mm)	30
	4.33	Aisle width for pallets 1000X1200 crossways	Ast(mm)	2564
	4.34	Aisle width for pallets 800X1200 lengthways	Ast(mm)	2529
	4.35	Turning radius	Wa(mm)	1700
Performance data	5.1	Travel speed,laden/unladen	Km/h	4/4.5
	5.2	Lift speed,laden/unladen	m/s	0.06/0.11
	5.3	Lowering speed,laden/unladen	m/s	0.09/0.06
	5.8	Max.gradeability,laden/unladen	%	3/7
	5.10	Service brake	/	Electromagnetic
Electric-engine	6.1	Drive motor rating S260min	Kw	0.75
	6.2	Lift motor rating at S34.5%	Kw	2.2
	6.3	Battery ac.to DIN 43531/35/36 A,B,C,no	/	/
	6.4	Battery voltage,nominal capacity K5	V/Ah	24/80(100)
	6.5	B Battery weight +/-5%	Kg	2×25
	6.6	Energy consumption acc:to VDI cycle	KWh/h	/
Additional data	8.1	Type of drive control	/	DC speed control
	8.4	Sound level at driver's ear acc.to EN 12053	DB(A)	69

Note:For other specification parameters,please refer to the attached table
