JCF-780 Lightweight Manual Push Industrial Sweeper

Lightweight Manual Push Industrial Sweeper JCF-780 Full English Product Page Content
1. Product Introduction
JCF-780 manual push sweeper has overall outer dimensions of 1085*795*1045mm, net weight 19.5KG and gross weight 22KG, delivering a working efficiency of 3800 square meters per hour with a 780mm cleaning width. It is fitted with a 2.6L water tank and a 50L waste dust bin, powered by 12V main brush motor and 12V side brush motor, with optional 20000mAh or 32000mAh lithium batteries to support minimum 2.5 or 5 hours of continuous operation. The machine configures 15W/30W water pump and 0.2mm/0.3mm spray nozzles for dust suppression during sweeping. Compact body structure enables access to narrow blind areas, detachable dust bin simplifies cleaning work, and manual push design reduces operation force with no complicated operation steps required.

2. Core Advantages
1. 780mm effective sweeping width supports 3800㎡ hourly cleaning coverage to shorten ground cleaning cycles
2. Dual lithium battery capacity options provide two tiers of continuous working duration to match different cleaning schedules
3. Separate water tank and spray system generates water mist to suppress dust during dry sweeping
4. 50L large-capacity dust bin extends intervals of waste dumping, with detachable design for direct flushing
5. Total net weight controlled at 19.5KG to lower physical force required for manual pushing operation

3. Product Features
Sweeping Power System
- 12V 30W main brush motor and 12V 40W side brush motor for synchronous ground sweeping
- 780mm overall working width, dual-brush layout to clean ground corners and narrow gaps
- Optional lithium battery modules: 20000mAh and 32000mAh, delivering ≥2.5h and ≥5h continuous operation respectively
Dust Suppression Water System
- 2.6L independent water storage tank matched with 15W/30W water pump
- Two specifications of spray nozzles at 0.2mm and 0.3mm to adjust mist output volume
Waste Storage & Body Structure
- 50L detachable dust bin for centralized collection of debris and ground dust
- Outer dimension 1085*795*1045mm, packing dimension 810*300*830mm for convenient transportation
- Net weight 19.5KG, gross weight 22KG, compact body to pass confined and corner spaces
Operation Structure
- Manual push structure without driving pedals or complex control panels
- Foldable push handle layout to reduce storage occupation space

4. Application Scenarios
This manual push sweeper operates on multiple hard ground materials including tile, epoxy floor, cement ground and terrazzo. It adapts to noise-restricted indoor and semi-indoor environments such as supermarkets, office buildings, hospitals, factory workshops, storage warehouses, underground parking lots and residential corridor passages.

5. Operation & Maintenance Notes
1. Empty all debris inside the dust bin after each operation and flush the bin with clean water to avoid dust caking
2. Check residual water volume inside the 2.6L water tank before dust suppression sweeping and add water when liquid level drops low
3. Clean blockages on spray nozzles regularly to maintain stable water mist output for dust control
4. Charge lithium batteries after daily use; avoid long-term storage with fully depleted battery power
5. Remove hair, thread and fiber debris tangled on main brush and side brush before each startup

6. Common Problems & Solutions
1. Insufficient dust suppression mist output
Solutions: Clear blockages inside spray nozzles, check water pump wiring connection, refill water tank with clean water
2. Short continuous working hours
Solutions: Complete full charging cycle, select higher capacity 32000mAh lithium battery module, inspect battery aging status
3. Debris leakage during sweeping
Solutions: Check sealing fit between dust bin and machine body, remove foreign objects blocking brush housing
4. Unsmooth pushing movement
Solutions: Clear tangled waste on main and side brushes, inspect wheel rotation for stuck sediment

7. Technical Parameter Description
The machine achieves working efficiency of 3800 square meters per hour with a 780mm working width. It contains a 2.6L water tank and a 50L dust bin, net weight 19.5KG and gross weight 22KG. Outer dimension measures 1085*795*1045mm and packing dimension is 810*300*830mm. Two lithium battery specifications are available: 20000mAh and 32000mAh, supporting continuous working time no less than 2.5 hours and 5 hours separately. It equips a 12V 30W main brush motor, a 12V 40W side brush motor, a 15W/30W water pump, and spray nozzles with 0.2mm and 0.3mm aperture sizes.
